Investing in
Solutions
Thanks to consistent investment in the latest equipment and software, our contract manufacturing capabilities are extensive, able to take on nearly any challenge.
Able to meet project requirements
At Robinson we are able to maximize efficiency and accuracy in every project. Our facilities total over 525,000 square feet and feature a wide array of equipment that helps us meet customers’ project requirements. Plus, we ensure our teams receive the training and tools necessary to get the job done right.
Robinson Facilities
and Equipment
De Pere
- De Pere 1 – 185,000 square foot facility
(28) Cranes 1/2 – 30 ton with 27′ under the hook
120 Ton Lifting Capacity - De Pere 2 – 178,000 square feet facility
(8) Cranes 10 – 20 ton with 16’ under the hook
Manitowoc
- 112,084 square foot facility
(13) Cranes 10 – 40 ton with 29’ under hook
120 ton Total Lifting Capacity
- G&P Stroke Sander
- (2) Vibratory Finishing Tumblers
- Falls DeBurring Machines
(2) Amada 9000 Watt Fiber Laser – 80″ x 160″ Table Size with automated load/unload and material tower
(1) Amada 6000 Watt Fiber Laser – 80″ x 160″ Table Size with automated load/unload and material tower
(1) Amada 6000 Watt CO2 Laser – 80″ x 160″ Table Size
- Capacity: ½” Stainless • 3/4″ Carbon
- Accuracy Range: ± .003 up to ±.005 or TBD/Matl.
(2) Wash Stations:
35’L X 12’W x12’H
(1) Wet Paint Booth:
60’L x 20’W x 14’H
(5) Powder Coating Booths:
(4) 35’L x 16’W x 16’H
(1) 65’L x 22’W x 16’H
(2) Dry-Off Ovens:
30’L x 12’W x 12’H
(5) Powder Coating Bake Ovens:
(4) 30’L x 12’W x 12’H
(1) 60’L x 18’W x 12’H
(1) Media Blasting Room:
60’L x 20’W x 14’H
MG Roller Double Pinch 4 Roll
(1) Amada: 350 Ton x 14′
(3) Amada: 242 Ton x 14′
(1) Amada: 242 Ton x 14′ with robotic forming
(3) RAS GIGAbend Metal Folding System
- Capacity 0.197″ Mild / 11 ga. Stainless
- Length 160″ Depth 61″ 130 Ton
(1) Amada: 110 Ton x 10′
- Capacity: 33 ton ▪ Travel 60″ x 98″ without reposition
- Accuracy: ± .005
Marvel Band Saw 380A-PC60
- Cutting Capacity 15″ x 20″
- 25: Blade 60 degree mitering left / right
Marvel 2150A P60 Auto Indexing
- Capacity: Rectangle 20″x 25″ Round 20″
Marvel Vertical Band Saw
- Capacity: 10″x 14″
(2) Klingelhofer Wet Cut Off Saws
(2) Accurshear: 3/16” x 12′ HR Steel Max
10 ga x 12′ SS Max
Lodge & Shipley: 10 ga. x 42″
- Boiler & Pressure Vessel U, S & R Stamp
- M.A.W. (Mig) & G.T.A.W. (Tig)
- C.A.W. (Flux-Core)
- A.W. (Submerged Arc Welding)
- Spray-Arc Steel
- Spot welding, Brazing and Soldering
- Laser Welder, Miller Optx, 2 kW
DE PERE 1 FACILITY
(28) Cranes 1/2 – 30 ton 27′ under hook
120 ton Lifting Capacity
DE PERE 2 FACILITY:
(8) Cranes 10 – 20 ton 16′ under hook
MANITOWOC FACILITY:
(14) Cranes 10 – 40 ton 29’ under hook
120 ton Lifting Capacity
(1) Combilift Straddle Carrier – 70 ton Lifting Capacity
14′ x 14’6″ x 40′
